64
3
Click [Robot Move] of the
“Robot Approach Pos.” on the
“Robot Operation Check” dialog
and move the robot to the
approach position.
WARNING
 These operations drive the robot.
 Operate the robot in the whereby pressing the [Emergency
stop] button can stop its motion anytime.
4
Click [Robot Move] of the
“Robot Command Pos.” on the
“Robot Operation Check” dialog
and move the robot to the
command position.
WARNING
 These operations drive the robot.
 Operate the robot in the state whereby pressing the
[Emergency stop] button can stop its motion anytime.
 Check the measurement results before operating the robot.
The robot may produce unexpected motion.
 Change positions and angles of the workpiece for Pick/Place
to check the operation sufficiently.
5
Stop the robot program
launched by procedures in
chapter 5.3.
