2.2 Attaching the Device
For first time use, remove the pad from the plastic
bag and attach it to the device. Do not remove the
plastic film on the back of the pad yet.
Note:
• To avoid damage, take care not to bend or damage
metal connectors.
Metal connector
1
Put the connector of
the pad through the
band port.
Connector
Pad
Band port
2
Hook one side of the
device onto the band.
3
Attach the connector
to the connection port
and push the device
until it clicks.
4
The pad and band are
now attached to the
device.
Make sure the connection
port is attached firmly to
the connector.
