Omron FS-C4KU7DGES-F - Input and Output Signal Timing (Hardware Trigger)

No.20S046-00
20/62
FS-C4KU7DGES-F / FS-C4KU7DGES-M42 / FS-C2KU7DGES-F / FS-C2KU7DGES-M42 / FS-C2KU7DGES-C
Product Specifications and Use’s Guide
Input and Output Signal Timing (Hardware Trigger)
Case of “External Hardware Trigger”, “Timed Exposure Mode” and “Positive Edge Trigger”
External hardware
Trigger signal
Trigger delay
Expose
Image out
Camera internal processing
FrameTriggerWait
ExposureActive
DebounceLine3, 4
FramTriggerInternal
SensorReadOut
Timer0, 1
Debounce
External hardware
Trigger delay
Tdelay (*1)
Parameter
“
ExposureTime
”
on GenICam
Parameter
“
LineDebounceTime
”
on GenICam
Parameter
“
TriggerDelay
”
on GenICam
Parameter
“
TimerDelay
”
on GenICam Parameter
“
TimerDuration
”
on GenICam
Line 1
Line 2
Line N
Line N-1
