Omron H3DS Series User Manual

H3DS-X
H3DS-X
28
Specifications
General
Item H3DS-X
Operating mode ON-delay
Operating/Reset method T ime-limit operation/self-resetting
Output type SCR output
External connections Screw terminal, screwless spring terminal
T erminal block Screw terminal type: Clamps two 2.5-mm
2
max. bar terminals without sleeves.
Screwless spring terminal type: Clamps two 1.5-mm
2
max. bar terminals without sleeves.
T erminal screw tightening
torque
0.98 N S m max.
Mounting method DIN track mounting (see note)
Attachment Nameplate label
Approved standards UL508, CSA C22.2 No.14
Conforms to EN61812-1, IEC60664-1 (VDE01
10) 4 kV/2, VDE0106/P100
Note: Can be mounted to 35-mm DIN T rack with a plate thickness of 1 to 2.5 mm.
Time Ranges
Time scale display T ime range
0.1 s 0.1 to 1.2 s
1 s 1 to 12 s
0.1 m 0.1 to 1.2 min
1 m 1 to 12 min
0.1 h 0.1 to 1.2 h
1 h 1 to 12 h
10 h 10 to 120 h
Note: When the time setting dial is set to “0” for any time scale, the output will operate instantaneously .
Ratings
Rated supply voltage (see note) 24 to 230 V AC/VDC (50/60 Hz)
Operating voltage range 85% to 1 10% of rated supply voltage
Power reset Minimum power-off time: 0.1 s
Reset voltage 1.0 V AC/VDC max.
Reset current 5 mA max.
Power consumption 5 mA max.
Control output SCR output: 5 mA to 0.7 A
Ambient temperature Operating: –10° C to 55 ° C (with no icing)
Storage: –25° C to 65 ° C (with no icing)
Ambient humidity Operating: 35% to 85%
Note: The ripple in DC power supply must be 5% max.

Omron H3DS Series Specifications

General

Type	Solid-state Timer
Operating Temperature	-10°C to 55°C
Output Type	Relay
Terminal Type	Screw terminals
Storage Temperature	-25°C to 65°C
Mounting	DIN Rail
Output	SPDT
Functions	On-Delay, Off-Delay, Interval, One-Shot
Protection Rating	IP20
Contact Form	SPDT
