H3DS-X
H3DS-X
29
Characteristics
Accuracy
of operating
time
±
1% max. of FS (
±
1%
±
10 ms max. at 1.2-s range)
Setting error ±
10%
±
50 ms max. of FS
Reset time
0.1 s max.
Influence of voltage
±
0.5% max. of FS (
±0.5%±
10 ms max. at 1.2-s range)
Influence of temperature
±
2% max. of FS (
±2%±
10 ms max. at 1.2-s range)
Insulation resistance
100 M
Ω
min. at 500 VDC
Dielectric strength
Between current-carrying metal parts and exposed non-current-carrying metal parts: 2,000 V
AC for 1 min
Impulse withstand
voltage
3 kV (between power supply terminals)
4.5 kV (between current-carrying metal parts and exposed non-current-carrying metal parts)
Noise immunity
Square-wave noise generated by noise simulator (pulse width: 100 ns/1
µs, 1-ns rise) ±
1.5 kV (between
power supply terminals)
Static immunity
Malfunction: 4 kV
Destruction: 8 kV
V
ibration resistance
Malfunction:
0.5-mm single amplitude at 10 to 55 Hz
Destruction:
0.75-mm single amplitude at 10 to 55 Hz
Shock resistance
Malfunction:
200 m/s
2
, 3 times each in 6 directions
Destruction:
300 m/s
2
, 3 times each in 6 directions
EMC (EMI)
Emission Enclosure: EN55011 Group 1 class B
Emission AC Mains:
EN55011 Group 1 class B
(EMS)
Immunity ESD:
EN61000-4-2:
6 kV contact discharge (level 3)
8 kV air discharge (level 3)
Immunity RF-interference from AM Radio W
aves: EN61000-4-3: 10 V/m (80 MHz to 1 GHz) (level 3)
Immunity Burst:
EN61000-4-4:
2 kV power port and output port (level 3)
1 kV control port with capacitive clamp (level 3)
Immunity Surge:
EN61000-4-5:
2 kV common mode (level 3)
1 kV dif
ferential mode (level 3)
Case color
Light gray (5Y7/1)
Degree of protection
IP30 (IP20 for terminal block)
Weight
Approx. 70 g
