in the configuration selection mode. The H7BX is also equipped with a DIP switch monitor function, a convenient function that enables the settings
of the DIP switch pins to be confirmed using the front display.
Up
Up
Up 1
Up 1
Up 1
Up 1
1 s min.
Key
Key
···Indicates that DIP switch pin 8 is ON.
···Indicates that DIP switch pin 7 is OFF.
···Indicates that DIP switch pin 6 is ON.
···Indicates that DIP switch pin 5 is OFF.
···Indicates that DIP switch pin 4 is ON.
···Indicates that DIP switch pin 3 is OFF.
···Indicates that DIP switch pin 2 is ON.
···Indicates that DIP switch pin 1 is ON.
Note: 1. The configuration that can be selected depend on the model.
(Tachometer)(Dual
counter)
(Twin
counter)
(Batch
counter)
(1-stage
counter)
(2-stage
counter)
(Total and
presetcounter)
Power ON
Example
Configuration
selection
Caution
DIP switch
monitor
(DIP)
Run Mode
Configuration Selection Mode
The status of the DIP switch pins (1 to 8) can be confirmed using the Keys.
Convenient
function
Note: This display is possible only if DIP switch pin 1 (DIP switch settings) is set to ON
(i.e., enabled).
*2 *1
2. The default setting is for a 1-stage preset counter. (For models with a 2-stage setting,
the default is for a 2-stage preset counter.)
*1. When the mode is changed to configuration selection mode, the present value is reset, outputs turns OFF, and counting (measuring) stops.
*2. Setting changes made in configuration selection mode are enabled when the mode is changed to run mode.
If the configuration is changed, the set value (or set value 1 and set value 2), OUT1 set value or OUT2 set value are initialized.
To change the mode to configuration selection mode, press
the Key for 1 s min. with the key held down.
The mode will not change if the Key is pressed first.
Select the configuration with any of the Keys.
ON
12345 6 7 8
twn
