H7CR
H7CR
14
H7CR-8❑, H7CR-11 Socket-Mount Types
Track and surface mounting height
Panel mounting depth
6
(0.24)
6
(0.24)
0.7
(0.03)
86 (3.39)
6
(0.24)
13.5 (0.53)
P2CF-08 Track Mounting/Front Connecting Socket
Two 4.5 dia.
holes
7.8
(0.31)
50 max.
(1.97)
Eight
M3.5 x 7.5 sems
3
(0.12)
4.5
(0.18)
20.3 max.
(0.80)
Two, 4.5 dia. or two
M4 socket mounting holes
Surface Mounting
Holes
4
(0.16)
Terminal Arrangement/
Internal Connections
(Top View)
40 ± 0.2
(1.57)
70 max.
(2.76)
35.4
(1.39)
P2CF-08-E Finger Safe Terminal Type
Conforming to VDE0106/P100
Eight
M3.5 x 7.5 sems
7.8
(0.31)
70 max.
(2.76)
Two 4.5 dia.
holes
50 max.
(1.97)
40±0.2
4.5
(0.18)
35.4
(1.39)
21.5 max
20.3
19
1.3
3
5
■ ACCESSORIES
72.5 (2.85)
