List of Settings Section 2
List of
Settings
Initial Setting Level
Note The values beginning with H' in the Monitor/Setting range column are used when setting or monitor-
ing data via communications.
Input Adjustment Level
Note The values beginning with H' in the Monitor/Setting range column are used when setting or monitor-
ing data via communications.
Variable
type
Address Parameter
name
Charac-
ter
Monitor/Setting range Character Default
setting
Decimal point Unit
C4 0010 Function func H’00000000 to H’00000005: (F1 to 6) f1 to 6f1--- ---
0001 Input type A in-ta H’00000000: No-contact (NO)
H’00000001: No-contact (NC)
H’00000002: Contact (NO)
H’00000003: Contact (NC)
00, 01, 10, 11 00 --- ---
0007 Input type B in-tb H’00000000: No-contact (NO)
H’00000001: No-contact (NC)
H’00000002: Contact (NO)
H’00000003: Contact (NC)
00, 01, 10, 11 00 --- ---
0011 Prescale AX ps. ax H’00000000 to H’0001869F: (0.0000 to 9.9999) 0. 0000 to 9. 9999 1. 0000 4---
0012 Prescale AY ps.
ay H’FFFFFFF7 to H’00000009: (−9 to 9) 10 -9 to 10 9 10 0 --- ---
0013 Prescale BX ps.
bx H’00000000 o H’0001869F: (0.0000 to 9.9999) 0. 0000 to 9. 9999 1. 0000 4---
0014 Prescale BY ps. by H’FFFFFFF7 to H’00000009: (−9 to 9) 10 -9 to 10 9 10 0 --- ---
0015 Time unit time H’00000000: OFF (0)
H’00000001: min (1)
H’00000002: hour: min: s (2)
H’00000003: min, s: 100 ms (3)
off, min,
h. mm. ss,
mm. ss. d
off --- ---
000D Decimal point
position
dp H’00000000 to H’00000004: (0 to 4) \\\\\, \\\\.
\,
\\\.
\\, \\. \\\,
\. \\\\
\\\\\ --- ---
000E Comparative
output pattern
out-p H’00000000: Standard outputs (0)
H’00000001: Zone outputs (1)
H’00000002: Level outputs (2)
nomal, zone,
level
nomal --- ---
Variable
type
Address Parameter
name
Charac-
ter
Monitor/Setting range Character Default
setting
Decimal point Unit
C5 0006 Averaging type a?g-t H’00000000: Simple average (0)
H’00000001: Moving average (1)
smpl, mo?e smpl --- ---
0007 Averaging times a?g-n H’00000000: 1 (0)/H’00000001: 2 (1)/
H’00000002: 4 (2)/H’00000003: 8 (3)/
H’00000004: 16 (4)/H’00000005: 32 (5)/
H’00000006: 64 (6)/H’00000007: 128 (7)/
H’00000008: 256 (8)/H’00000009: 512 (9)/
H’0000000A: 1,024 (10) times
1, 2, 4, 8, 16, 32,
64, 128, 256,
512, 1024
1 --- ---
000C Auto-zero time A
at. za H’00000000 to H’0000752F: (0.0 to 2999.9) 0. 0 to 2999. 9 2999. 9 1s
000D Auto-zero time B
at. zb H’00000000 to H’0000752F: (0.0 to 2999.9) 0. 0 to 2999. 9 2999. 9 1s
0010 Power supply
memory
memo H’00000000: OFF (0), H’00000001: ON (1) off, on off --- ---
