28 Digital Indicators K3HB-X/-V/-H/-S
■ Output
The output pattern for comparative outputs can be selected. In addi-
tion to high/low comparison with set values, output based on level
changes is also possible. (Use the type of output pattern appropriate
for the application.)
Reverses the output operation of comparative outputs for compara-
tive results.
Prevents comparative output chattering when the measurement
value fluctuates slightly near the set value.
Measurement can be stopped for a set time using external input.
Comparative results other than PASS and error signals can be output
from the PASS output terminal.
■ Dimensions
Comparative Output Pattern
Output Logic
X V H S
ON
OFF
ON
OFF
ON
OFF
Standard Output
Zone Output
Comparative
set value HH
Comparative
set value H
Comparative
set value L
Comparative
set value LL
Measurement
value
Higher
Lower
Output HH
Output PASS
Output H
Output L
Output LL
Measurement
value
Higher
Lower
Measurement
value
Higher
Lower
Comparative
set value HH
Comparative
set value H
Comparative
set value L
Comparative
set value LL
Output HH
Output PASS
Output H
Output L
Output LL
Comparative
set value HH
Comparative
set value H
Comparative
set value L
Comparative
set value LL
Output HH
Output PASS
Output H
Output L
Output LL
Level Output
X V H S
Hysteresis
Startup Compensation Timer
PASS Output Change
X V H S
Example: Comparative Output Pattern (Standard Output)
Comparative set value H
Hysteresis
Hysteresis
Comparative set value L
Comparative output L
Comparative output H
X V H S
Input
H comparative set value
H output
H input
Tim
Startup com-
pensation time
set time
X V H S
Terminal cover (included)
14.2
4.9
3.5
7.6
96
48
1.3
12
(112)
100
101.2
91
95*
2
44.8
120 min.
45
+0.6
0
92
+0.8
0
75 min.
Character Size for Main Display (mm)
PV display SV display
*DeviceNet models: 97 mm
Terminal: M3, Terminal Cover: Accessory
Panel Cutout Dimensions
