Omron LD Series User Manual

5
LD Series
Appearance Description Specification Configuration & Attachment Part Number
Docking
Station
A docking station to charge the
battery installed in the mobile
robot.
– Docking station, AC power cable 12477-000
Extended
Wall mount
Docking station, AC power cable, extended wall mount
(for Cart Transporter)
12477-050
Joystick
Used for manually controlling
the mobile robot
Cable length: 0.6
to 3 m
– 13558-000
Breakout Cable
A D-SUB44 pin cable for digital
I/O interface of the mobile robot.
–
DB44HD breakout cable
(D-SUB44 pin cable for digital I/O interface)
14165-000
Top Plate - LD-
60, LD-90
A upper plate of the mobile
robot OEM. It is not necessary for
building customer payload
Top cover for
OEM type
LD-60
LD-90
12944-000
Top Plate -
LD-250
A upper plate of the mobile
robot OEM. It is not necessary for
building customer payload
Top cover for
OEM type
LD-250 20458-002
Cart*
A cart designed to work
seamlessly with the mobile
robot cart transporter.
–
The cart only applies to LD-CT models.
75020-000
Battery
charging cable
A cable to connect a battery
and docking station to charge
the battery outside of the
mobile robot
Cable length: 0.45 m – 12676-000L
Fleet Management Solutions
Appearance Product Name Specification Configuration & Attachment
Part
Number
Primary Fleet Manager
EM2100 Appliance with 120 day temporary Fleet
Operations Workspace License
20271-900
Secondary Fleet Manager
EM2100 Appliance with 120 day temporary Fleet
Operations Workspace License
20271-901
Fleet Simulator
Simulation of up to
10 AMRs
EM2100 Appliance with Simulation license included 20271-903
5 Year License (Primary Fleet Management) 5 year license activation for primary fleet management 20271-806
5 Year License (Secondary Fleet
Management)
5 year license activation for secondary fleet management 20271-807
Fleet Simulator License
Simulation of up to
10 AMRs
License activation for Fleet Simulation (Add-on License
for Primary or Secondary Fleet Managers)
20271-804
MobilePlanner Version 4.x
Installer (USB)*
License Dongle
MSS 4.x compatible only (NOT COMPATIBLE with
FLOW Core)
13495-200
* To obtain the latest version of the Fleet Operations Workspace (FLOW) Core software, contact your local OMRON representative.
