Omron MX2 Product Information

MX2 5
Option board
Input AC reactor
DC Reactor
Output AC Reactor
Voltage Reference
Dimensions Weight
kg
A
B2 C2 D E F
200 V
AX-RAI02800080-DE 120 70 120 80 52 5.5 1.78
AX-RAI00880200-DE 120 80 120 80 62 5.5 2.35
AX-RAI00350335-DE 180 85 190 140 55 6 5.5
AX-RAI00180670-DE 180 85 190 140 55 6 5.5
400 V
AX-RAI07700050-DE 120 70 120 80 52 5.5 1.78
AX-RAI03500100-DE 120 80 120 80 62 5.5 2.35
AX-RAI01300170-DE 120 80 120 80 62 5.5 2.50
AX-RAI00740335-DE 180 85 190 140 55 6 5.5
Voltage Reference
Dimensions Weight
kg
A
B C D E F G H
200 V
AX-RC21400016-DE
84 113
96
101 66 5 7.5 2
1.22
AX-RC10700032-DE
AX-RC06750061-DE
105 1.60
AX-RC03510093-DE
AX-RC02510138-DE
116 1.95
AX-RC01600223-DE
108 135 124 120 82 6.5
9.5
9.5 3.20
AX-RC01110309-DE
120 152
136
135 94
7-
5.20
AX-RC00840437-DE
146 6.00
AX-RC00590614-DE
150 177
160
160 115 2
11.4
AX-RC00440859-DE
182.
6
14.3
400 V
AX-RC43000020-DE
84 113
96
101 66 5 7.5 2
1.22
AX-RC27000030-DE
105 1.60
AX-RC14000047-DE
AX-RC10100069-DE
116 1.95
AX-RC06400116-DE
108 135 133 120 82 6.5
9.5
9.5 3.70
AX-RC04410167-DE
120 152
136
135 94 7
-
5.20
AX-RC03350219-DE
146 6.00
AX-RC02330307-DE
150 177
160
160 115 7 2
11.4
AX-RC01750430-DE
182.
6
14.3
Voltage Reference
Dimensions Weight
kg
A
B2 C2 D E F
200 V
AX-RAO11500026-DE 120 70 120 80 52 5.5 1.78
AX-RAO07600042-DE 120 70 120 80 52 5.5 1.78
AX-RAO04100075-DE 120 80 120 80 62 5.5 2.35
AX-RAO03000105-DE 120 80 120 80 62 5.5 2.35
AX-RAO01830180-DE 180 85 190 140 55 6 5.5
AX-RAO01150220-DE 180 85 190 140 55 6 5.5
AX-RAO00950320-DE 180 85 205 140 55 6 6.5
AX-RAO00630430-DE 180 95 205 140 65 6 9.1
AX-RAO00490640-DE 180 95 205 140 65 6 9.1
31.3

Omron MX2 Specifications

General

Model	MX2
Category	Inverter
Enclosure Rating	IP20
Control Method	V/f control, Sensorless vector control
Frequency Range	0.1 to 400 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat, Short circuit
Communication	Modbus RTU
Ambient Temperature	-10 to 50 °C (without freezing or condensation)
Overload Capacity	150% for 60 seconds
Cooling Method	Fan Cooled
Humidity	5 to 95% RH (without condensation)
Altitude	Up to 1000m without derating
Voltage	200-240 VAC, 380-480 VAC
Braking Unit	Built-in (for certain models), Optional External
