3 Connecting to Mitsubishi PLCs
3-30
NB-series Programmable Terminals Host Connection Manual (V108)
Mitsubishi FX2N-10GM/20GM Driver
*1 does not support batch transmission while
*2 supports batch transmission.
Mitsubishi FX3U Driver
*1 The operations accessed beyond the limit is not guaranteed.
Mitsubishi FX-485ADP/485BD/232BD (Multi-station) Driver
Device Bit Address Word Address Format Notes
Input Relay X 0-571 ------ OOO *1
Output Relay Y 0-571 ------ OOO *1
Internal Relay M 0-7999 ------ DDDD *1
Special Internal Relay SM 9000-9999 ------ DDDD *1
Data Register ------ D 0-7999 DDDD *2
Special Data Register ------ SD 9000-9999 DDDD *2
Special Data Register ------ FD 4000-4550 DDDD *2
Present position ------ CP_unit 0-1 D D9004-9005
D9014-9015
Present position
(converted into pulses)
------ CP_puls 0-1 D D9074-9075
D9094-9095
Device Bit Address Word Address Format Notes
Input Relay X 0-764 ------ OOO
Output Relay Y 0-764 ------ OOO
Timer Contact T_bit 0-511 ------ DDD
Counter Contact C_bit 0-255 ------ DDD
Data Contact D_bit 0.0-7999.F ------ DDDD.H
State S 0-4095 ------ DDDD
Internal Relay M 0-7999 ------ DDDD *1
Special Internal Relay SM 8000-9999 ------ DDDD
Timer Value ------ T_word 0-511 DDD
Counter Value ------ C_word 0-199 DDD
Data Register ------ D_word 0-17999 DDDDD
Extension Register ------ R 0-32767 DDDDD
Special Data Register ------ SD 8000-9999 DDDD
Counter Value ------ C_dword 200-255 DDD 32 bit device
Device Bit Address Word Address Format Notes
Input Relay X 0-571 ------ OOO
Output Relay Y 0-571 ------ OOO
Timer Contact T_bit 0-511 ------ DDD
Counter Contact C_bit 0-255 ------ DDD
State S 0-4095 ------ DDDD
Internal Relay M 0-7679 ------ DDDD
Special Internal Relay SM 8000-8511 ------ DDDD
Timer Value ------ T_word 0-511 DDD
Counter Value ------ C_word 0-255 DDD
Data Register ------ D 0-7999 DDDD
FIle Register ------ R 0-32767 DDDDD
Special Data Register ------ SD 8000-8511 DDDD
Counter Value ------ C_dword 0-2047 DDDD 32 bit device
