3 Connecting to Mitsubishi PLCs
NB-series Programmable Terminals Host Connection Manual (V108)
3-4 Supported Registers
3
Mitsubishi Q00J (CPU Port) Driver
Mitsubishi Q_QnA (Link Port) Driver
Device Bit Address Word Address Format Notes
Counter Coil CC 0-1023 DDDD
Counter Contact CS 0-1023 DDDD
Timer Coil TC 0-2047 DDDD
Timer Contact TS 0-2047 DDDD
Special Link Relay SB 0-7FFF ------ HHHH
Link Relay B 0-7FFF ------ HHHH
Step Relay S 0-1FFF ------ HHHH
Edge Relay V 0-32767 ------ DDDDD
Annunciator F 0-32767 ------ DDDDD
Latch Relay L 0-32767 ------ DDDDD
Special Internal Relay SM 0-2047 ------ DDDD
Internal Relay M 0-32767 ------ DDDDD
Output Relay Y 0-1FFF ------ HHHH
Input Relay X 0-1FFF ------ HHHH
File Register ------ R 0-32767 DDDDD
Special Link Register SW 0-7FF HHH
Link Register ------ W 0-291F HHHH
Special Data Register ------ SD 0-2047 DDDD
Data Register ------ D 0-25983 DDDDD
Counter Value ------ CN 0-23087 DDDDD
Retentive Timer Value ------ SN 0-2047 DDDD
Timer Value ------ TN 0-23087 DDDDD
Device Bit Address Word Address Format Notes
Special Link Relay SB 0- 7FFF ------ HHHH
Link Relay B 0- 7FFF ------ HHHH
Step Relay S 0-8191 ------ DDDD
Edge relay V 0-32767 ------ DDDDD
Annunciator F 0-32767 ------ DDDDD
Latch relay L 0-32767 ------ DDDDD
Special Internal Relay SM 0-2047 ------ DDDD
Internal Relay M 0-32767 ------ DDDDD
Output Relay Y 0-1FFF ------ HHHH
Input Relay X 0-1FFF ------ HHHH
Link Register ------ W 0- 291F HHHH
Timer Value ------ TN 0-23087 DDDDD
Counter Value ------ CN 0-23087 DDDDD
Index Register ------ Z 0-19 DD
File Register ------ R 0-32767 DDDDD
Retentive Timer Value ------ SN 0-23087 DDDDD
Special Link Register ------ SW 0- 7FF HHH
File Register
(Block switching is not necessary)
------ ZR 0-65535 DDDDD
Data Register ------ D 0-25983 DDDDD
Special Data Register ------ SD 0-2047 DDDD
