3 Connecting to Mitsubishi PLCs

3-32

NB-series Programmable Terminals Host Connection Manual (V108)

Mitsubishi Q series (CPU Port) Driver

*1 Supports only Q06UDH.

Mitsubishi Q06H Driver

Device Bit Address Word Address Format Notes

Special Link Relay SB 0-7FFF ------ HHHH

Link Relay B 0-7FFF ------ HHHH

Edge Relay V 0-32767 ------ DDDDD

Annunciator F 0-32767 ------ DDDDD

Latch Relay L 0-32767 ------ DDDDD

Special Internal Relay SM 0-2047 ------ DDDD

Internal Relay M 0-32767 ------ DDDDD

Output Relay Y 0-1FFF ------ HHHH

Input Relay X 0-1FFF ------ HHHH

Step Relay S 0 -8191 ------ DDDD

Link Register ------ W 0-291F HHHH

Timer Value ------ TN 0-23087 DDDDD

Counter Value ------ CN 0-23087 DDDDD

File Register ------ R 0-32767 DDDDD

Special Link Register ------ SW 0-7FF HHH

Data Register ------ D 0-25983 DDDDD

Special Data Register ------ SD 0-2047 DDDD

Index Register ------ Z 0-19 DD

File Register

(Block switching is not

necessary)

------ ZR 0-4184063 DDDDDDD *1

Retentive Timer Value ------ SN 0-23087 DDDDD
