Omron NJ Series Network Connection Guide

9. Appendix 1 Detailed Settings of the Tag Data Links
49
SYNCFLG: Measurement synchronization completion bit: Turns ON when
the displacement sensor executes measurement synchronization
processing and the state changes to one where normal measured
values can be output.
READY: Ready bit: Turns ON when the displacement sensor can execute
control commands or measurement synchronization processing.
RUN: Run screen bit: Turns ON when the displacement sensor is in the
RUN mode.
BANK1_A to E (BANKOUT1_A to E): Current bank number bit: Outputs the
currently specified bank number. It expresses the bank number in
combinations of BANKOUTx_A to E.
ERR: Error bit: Turns ON when a displacement sensor error is detected.
Allocation of EIPInput.CommonStatusFlag.W variable
Offset (word) 15 14 13 … 2 1 0
+0
15 14 13 … 2 1 0
+1
31 30 29 … 18 17 16
Bits 31 to 0: EIPInput.CommonStatusFlag.W uses DWORD data from offset
+ 2 words.
*5: Details on allocation of sensor head 1 status signal
Allocation of EIPOutput.SensorHead1StatusFlag.F variable
Offset
(word)
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
+2
OR1
GATE
1
ENABLE
1
STABLIT
Y1
LIGHT1
RESET
STAT1
HOLD
STAT1
+3
LOW1
_T1
PASS1
_T1
HIGH1
_T1
LOW1
_T1
PASS1
_T1
HIGH1
_T1
LOW1
_T1
PASS1
_T1
HIGH1
_T1
LOW1
_T1
PASS1
_T1
HIGH1_
T1
LOW1_T
1
PASS1_
T1
HIGH1_
T1
LOW1_T
1
HOLDSTAT1: Hold execution status bit: Turns ON when the displacement
sensor is in the hold sampling period.
RESETSTAT1: Reset execution state bit: Turns ON when the displacement
sensor is in the reset execution state.
LIGHT1: Logical beam lighting state bit: Turns ON when the logical beam is lit.
STABILITY1: Measurement position bit: Turns ON when the measured value is
in the measuring range.
ENABLE1: Measurement state bit: Turns ON when the displacement sensor is
ready for measurement.
GATE1: Data output completed bit: Turns ON when the displacement sensor
completes control data output when hold is set.
OR1: Overall judgment result bit: Turns ON when even one of the judgment
result of the displacement sensor TASK1 to 4 is other than
PASS.
ZEROSTAT1_T1 to 4: Zero reset bit: Turns ON when the displacement sensor
TASK1 to 4 is in the zero reset execution state.
