Omron NJ Series Connection Guide

7．EtherCAT Connection Procedure
19
4
Node address 1, E001 and
HES-M400 Rev:0x00000000
are added to the Network
configuration on Sysmac Studio.
Confirm that the data above are
added and click the Close
Button.
5
Node address 1, E001, and
HES-M400 Rev:0x00000000
are added to the EtherCAT Tab
Page on the Edit Pane.

Omron NJ Series Specifications

General

Program Capacity	Up to 128 MB
SD Card Slot	Yes
Power Supply Voltage	24 VDC
Motion Control	Yes
USB Ports	1
Operating Temperature	0°C to 55°C
Communication Interfaces	Ethernet/IP, EtherCAT, USB
Safety Function	Optional
Storage Temperature	-20°C to 75°C
Communication Ports	USB
Dimensions	Varies by model
Weight	Varies by model
