4-1SectionConnecting to the RS-232C Port at the Host
57
When using the peripheral port of a CS1G/H, CS1G/H-H, or CJ1G
Word Value Settings
CIO
144
8200 1:N NT Link mode
CIO 145
0000 to 0009
(*1)
Communications baud rate (standard)
CIO 150 000j
j = The largest model number of the
connected PT (0 – 7)
*1 Set any value between 0000 and 0009 Hex for the communications baud rate.
The same baud rate will be used regardless of the value as long as it is between
0000 and 0009 Hex.
When
connecting PT
s with
model numbers 0 and 2 to 5 to the built-in RS-232C
port, for example, set CIO 160 to 8200 Hex, CIO 161 to 0000 Hex and set
CIO166 to 0005 Hex.
Either set PC Setup directly from a Programming Device (Programming Con-
sole),
or transmit the PC Setup made at a
Programming Device (CX-Program
-
mer)
to the CPU Unit. For details on PC Setup,refer
to the
SYSMAC CS Series
Operation Manual (W339-E1-j) or SYSMAC CJ Series Operation Manual
(W393-E1-j).
To Next Page
