4-1SectionConnecting to the RS-232C Port at the Host
64
Name Delivered withRemarksModel
XM2S-0911
9-pin
Made by OMRON
C-series CQM1,
C200HS,
C200HX/HG/HE-(Z)E,
CVM1/CV-series CPU
Units
CV500-LK201
Connector
hood
XM2S-0913
9-pin
Made by OMRON
---
hood
XM2S-0911-E
9-pin
Made by OMRON
CS-series CS1G/CS1H,
CS1G-H/CS1H-H
CJ-series CJ1G
XM2S-2511
25-pin
Made by OMRON
CV500-LK201
C200H-LK201-EV1
AWG28 5P
IFVV-SB
Multi-core shielded cable
Made by Fujikura, Ltd.
---
Cable
CO-MA-VV-SB
5P 28AWG
Multi-core shielded cable
Made by Hitachi Cable,
Ltd.
---
Note After connecting a communication cable, always secure it with the screws.
Otherwise the cable may disconnect, causing operation to fail.
OMRON Cables with Connectors
The OMRON cables listed below can be used when connecting with a method
other than the memory link method.
Model Cable Length Connector Specification
XW2Z-200S 2 m
9 pin ⇔ 25 pin
XW2Z-500S 5 m
9-pin ⇔ 25 pin
XW2Z-200T 2 m
9 pin ⇔ 9 pin
XW2Z-500T 5 m
9-pin ⇔ 9-pin
The OMRON cable listed below can be used when connecting to a personal
computer with the memory link method.
Model Cable Length Connector Specification
XW2Z-S002 2 m 9-pin ⇔ 9 pin
Note The cable’s tensile load is 30 N. Do not subject it to loads greater than this.
Otherwise a discontinuity may occur, causing operation to fail.
Applicable Units: C200H-LK201-EV1
CV500-LK201 (communication port 1)
Compatible cables with attached connectors:
XW2Z-200S (9-pin
⇔ 25-pin, 2 m)
XW2Z-500S (9-pin
⇔ 25-pin, 5 m)
CVM1/CV-series
Host Link Units (CV500-LK201) have two types of connector; a
25-pin connector (communication port 1), and a 9-pin connector (communica-
Wiring for a Host Link
Unit (25-pin) Connection
