4-1SectionConnecting to the RS-232C Port at the Host
65
tion port 2). When using communication port 2, refer to W iring for Other Connec -
tions (Other Than the Memory Link Method) (page65).
1
6
5
9
*
NT21
114
13 25
FG
+5V
CS
RS
RD
SD
5G
1
2
3
4
5
6
7
8
9
2
3
4
5
6
7
8
–
–
–
–
FG
5G
CS
RS
RD
SD
ER
–
–
–
–
–
PC (Host Link Unit)
(25-pin type)
(9-pin type)
RS-232C
interface
RS-232C
interface
Abbreviation
Pin
number
Abbreviation
Pin
number
Connector
hood
Shield
Connector
hood
* For Units that have a CTS setting selector switch, RS and CS do not have to be
shorted if this switch is set to 0V.
Applicable Units:
CV500-LK201 (communication port 2)
CS1W-SCU21 CJ1W-SCU41
CPM1-10CDR-j CPM1-20CDR-j
CPM1-30CDR-j
CPM1A-10CDj-j CPM1A-20CDj-j
CPM1A-30CDj-j CPM1A-40CDj-j
CPM2A-30CDj-j CPM2A-40CDj-j
CPM2A-60CDj-j
CPM2C-10jjjjjj-j CPM2C-20jjjjjj-j
CQM1-CPU21-E
CQM1-CPU41-EV1 CQM1-CPU42-EV1
CQM1-CPU43-EV1 CQM1-CPU44-EV1
CQM1H-CPU11 CQM1H-CPU21
CQM1H-CPU51 CQM1H-CPU61
CS1G-CPU42-E(V1) CS1G-CPU43-E(V1)
CS1G-CPU44-E(V1) CS1G-CPU45-E(V1)
CS1H-CPU63-E(V1) CS1H-CPU64-E(V1)
CS1H-CPU65-E(V1) CS1H-CPU66-E(V1)
CS1H-CPU67-E(V1)
CS1G-CPU42H CS1G-CPU43H
CS1G-CPU44H CS1G-CPU45H
CS1H-CPU63H CS1H-CPU64H
CS1H-CPU65H CS1H-CPU66H
CS1H-CPU67H
CJ1G-CPU44 CJ1G-CPU45
C200HS-CPU21-E, -EC C200HS-CPU23-E
C200HS-CPU31-E C200HS-CPU33-E
C200HE-CPU32-(Z)E C200HE-CPU42-(Z)E
C200HG-CPU33-(Z)E C200HG-CPU43-(Z)E
C200HG-CPU53-(Z)E C200HG-CPU63-(Z)E
C200HX-CPU34-(Z)E C200HX-CPU44-(Z)E
C200HX-CPU54-(Z)E C200HX-CPU64-(Z)E
C200HX-CPU65-ZE C200HX-CPU85-ZE
CVM1-CPU01-EV2 CVM1-CPU11-EV2
CVM1-CPU21-EV2
SRM1-C02-V2
