4 Installation and Wiring
4 - 22
NX-series Position Interface Units User’s Manual (W524)
Precautions for Correct Use
• Use cables with suitable wire sizes for the carrying current. There are also restrictions on the
current due to the ambient temperature. Refer to the manuals for the cables and use the
cables correctly for the operating environment.
• For twisted wires, strip the sheath and twist the conductor portion. Do not unravel or bend the
conductor portion of twisted wires or solid wires.
Additional Information
If more than 2 A will flow on the wires, use plated wires or use ferrules.
Terminals Wire type Wire plating
Wire size
Conductor
length (strip-
ping length)
Classifica-
tion
Current
capacity
Twisted
wires
Solid
wire
Plated Unplated
All terminals
except
ground termi-
nals
2 A max. Possible Possi-
ble
Possi-
ble
Possible
0.08 to 1.5 mm
2
(AWG 28 to 16)
8 to 10 mm
Greater than
2 A and 4 A
or less
Not possi-
ble
Greater than
4 A
Not
possi-
ble
Ground ter-
minals
*1
*1. With the NX-TB1 Terminal Block, use twisted wires to connect the ground terminal. Do not use a solid
wire.
--- Possi-
ble
Possible
2.0 mm
2
9 to 10 mm
Conductor length (stripping length)
Unravel wires Bent wires
NG
NG
