4 Installation and Wiring

4 - 28

NX-series Digital I/O Unit User’s Manual (W521)

 Types of Coding Pins

There are two types of Coding Pins, both with their own unique shape: one for terminal blocks and

one for Units.

Three pins come with each runner.

Use the following Coding Pins.

Name Model Specification

Coding Pin NX-AUX02 For 10 Units

(Terminal Block: 30 pins, Unit: 30 pins)

For Terminal Block For Unit

Coding Pins (Use this part.)

Runners

Introduction3
