To Next Page

To Previous Page

Current when IOG line is broken

IOG

So0

IOV

NX-ECCo

NX-SOo

Disconnected.

I/O power supply (24 VDC)

Load

Use the wiring that is shown in the following figure to prevent a floating condition for the IOG of the

Safety Output Unit even if the IOG line is broken.

I/O power supply (24 VDC)

Load

NX-ECCo

NX-SOo

IOG

So0

IOV

Connecting Output Devices

This section describes the connection methods for output devices.

Safety Relays and Contactors

Connect a safety relay or contactor as shown in the following figure.

4 Safety Control Unit Operation

4 - 33

NX-series Safety Control Unit User's Manual (Z930)

4-3 Safety I/O Function

4-3-2 Safety Output Function
