A-16
Differences in Checking Operation
between the Simulator and Safety
CPU Unit
This section describes the differences in the program debugging functions that you can perform on the
Sysmac Studio between online debugging on a Safety CPU Unit and offline debugging with the Simu-
lator.
Debugging function
Safety CPU
Unit
Simulator Reference
Monitoring
Supported. Supported.
7-6-3 Monitoring Variables in the FBD Editor on
page 7 - 28
7-6-4 Monitoring V
ariables in a W
atch Tab Page on
page 7 - 29
Monitoring in a Watch
Tab Page
Supported.
Supported.
7-6-5 Controlling BOOL Variables, Changing
Present Values, and Using Forced Refreshing on
page 7 - 31
Controlling BOOL vari-
ables
Supported. Supported.
Forced refreshing in-
puts
Supported. Supported.
Changing present val-
ues of data
Supported. Supported.
Monitoring Controller
status
Supported. Supported.
7-13 Monitoring Controller Status on page 7 - 64
Clear All Memory
Supported.
Not support-
ed.
7-14-2 Clear All Memory Operation on page 7 - 67
Changing the operat-
ing mode
Supported.
Not support-
ed.
7-3 Operating Modes of the Safety CPU Unit on
page 7 - 1
1
T
roubleshooting
Supported.
Not support-
ed.
Section 12 Troubleshooting on page
12 - 1
Monitoring error infor-
mation
Supported.
Not support-
ed.
Displaying error logs
Supported.
Not support-
ed.
Appendices
A - 104
NX-series Safety Control Unit User's Manual (Z930)
