Item Display content Related parameters
Program
Memory
Displays the memory usage of
the safety program.
• Number of the connected Safety I/O Units
• Number of CIP Safety connections, number of target I/O As-
semblies
• Number of functions blocks and functions in the safety pro-
gram
• Number of exposed variables, global variables and device
variables
• Comment sizes for exposed variables, global variables, and
device variables
• Function block names
• Number of device settings in the Safety Slave Unit parame-
ter settings
• T
erminal comments in the parameters for Safety Slave Units
Project Main-
tenance Data
Displays the memory usage of
the project.
• Program names
• Number of exposed variables
• Comment sizes for exposed variables, global variables, and
device variables
• Number of device settings in the Safety Slave Unit parame-
ter settings
• T
erminal comments in the parameters for Safety Slave Units
Number of
Safety I/O
connections
Displays the number of safety
slaves connected to the Safe-
ty CPU Unit.
FSoE
shows the number of
connections with Safety I/O
Units. CIP shows the number
of CIP Safety connections.
• Number of the connected Safety I/O Units
• Number of CIP Safety connections, number of target I/O As-
semblies
Input Data
Sizes
Displays the input data usage
by the Safety CPU Unit.
• Number of the connected Safety I/O Units
• Number of CIP Safety connections
• Data size of the exposed variables used for input settings
Output Data
Sizes
Displays the output data us-
age by the Safety CPU Unit.
• Number of the connected Safety I/O Units
• Number of CIP Safety connections
• Data size of the exposed variables used for output settings
Exposed In-
put Variables
Displays the number of ex-
posed variables in the input
settings.
Number of exposed variables used for input settings
Exposed Out-
put Variables
Displays the number of ex-
posed variables in the output
settings.
Number of exposed variables used for output settings
