Tools Required for Inspections

Required Tools

• Phillips screwdriver

• Flat-blade screwdriver

•

Voltage tester or digital voltmeter

• Industrial alcohol and pure cotton cloth

Tools Required Occasionally

• Oscilloscope

• Thermometer and hygrometer

13 Inspection and Maintenance

13 - 4

NX-series Safety Control Unit User's Manual (Z930)
