Pin Operations
This section describes the procedures to create and delete pins, and the jump function.
l
Creating Pins
When you click the Pin project Button, a dialog box to enter the current status name is displayed.
The name that you set is shown as the pin information in the upper part of the Change Tracking
T
ab Page.
If the data changes from the data that is in effect at this point, the contents of the change are dis-
played in the tab page.
l
Deleting a Pin
When you click the Clear Pin Button, the status that you created with the Pin project Button is
deleted.
l
Jump Function
When you double-click information on the Change Tracking Tab Page, the global variable table,
FBD editor, or other corresponding tab page is displayed.
Appendices
A - 71
NX-series Safety Control Unit User's Manual (Z930)
A-4 Change Tracking
