Port
Data type
R/W
Name
Description
Default
Corre-
spond-
ing port
name
So03 Status
BOOL
R
So03 Status
Gives the status of safety output termi-
nal 03.
0: Error
1: No error
0
---
Appendices
A - 80
NX-series Safety Control Unit User's Manual (Z930)
591
593
