General
Status
(hex)
Additional
Status
(hex)
Explanation
01 0317 Either the segment is not present or the encoded value in the network segment is
invalid.
01 0318 Link address to self is invalid.
01 0319 Resources on secondary are unavailable.
01 031A Connection is already established.
01 031B Direct connection is already established.
01 031C Others
01 031D Redundant connection mismatch.
01 031E There are no more reception resources available on the sending module.
01 031F No connection resources exist for the target path.
01 0320 - 07FF Vendor specific.
01 0801 Incompatible Multicast RPI. An existing connection has been established at a dif-
ferent RPI.
01 0802 Invalid Safety Connection Size
01 0803 Invalid Safety Connection Format
01 0804 Invalid Time Correction Connection Parameters
01 0805 Invalid Ping Interval EPI Multiplier
01 0806 Time Coordination Msg Min Multiplier
01 0807 Network Time Expectation Multiplier
01 0808 Timeout Multiplier
01 0809 Invalid Max Consumer Number
01 080A Invalid CPCRC
01 080B Time Correction Connection Id Invalid
01 080C SCID Mismatch. The SCID was non-zero and did not match the value in the tar-
get
01 080D TUNID not set. Device is out-of-box and TUNID has not been set, so connections
are not allowed.
01 080E TUNID Mismatch. The TUNID provided does not match. The message was likely
routed to this node in error
01 080F Configuration operation not allowed
01 0810 No target application data available
01 0811 No originator application data available
01 0812 Node address has changed since the network was scheduled
01 0813 Not configured for off-subnet multicast
01 0814 Invalid Produce/Consume Data Format
Appendices
A - 85
NX-series Safety Control Unit User's Manual (Z930)
A-7 CIP Response Codes
A
A-7-2 Extended Status Codes
