Category Device Settable external device icons

Safety Switch Safety key selector switch

for dual-channel equivalent input

Safety key selector switch

for dual-channel complementary input

Safety key selector switch

for single channel

Enabling switch

Safety Sensor Safety light curtain

Safety laser scanner

Specialty devices Non-contact Door Switch

Single Beam Safety Sensor

Safety Mat/Safety Edge

EDM Feedback EDM Feedback

Standard Input De-

vice

Reset switch with test pulse

Reset switch without test pulse

Appendices

A - 87
