Safety Control Unit model and version NX bus master: CPU Unit
Model Unit version NX102 CPU Unit Sysmac Studio
NX-SL3300 Ver. 1.0 Ver. 1.30 Ver. 1.22
Ver. 1.1
NX-SL3500 Ver. 1.0
Ver. 1.1
NX-SL5500 Ver. 1.3 Ver. 1.31 Ver. 1.24
NX-SL5700 Ver. 1.2 --- ---
Ver. 1.3 Ver. 1.31 Ver. 1.24
NX-SIH400 Ver. 1.0 Ver. 1.30 Ver. 1.22
Ver. 1.1
NX-SID800 Ver. 1.0
NX-SOH200
NX-SOD400
Safety Control Unit model and version NX bus master: Communication Control Unit
Model Unit version
NX-CSG£££
Sysmac Studio
NX-SL3300 Ver. 1.0 --- ---
NX-SL3300 Ver. 1.1
NX-SL3500 Ver. 1.0
NX-SL3500 Ver. 1.1
NX-SL5500 Ver. 1.3 Ver. 1.01 Ver. 1.24
NX-SL5700 Ver. 1.2 Ver. 1.00 only
NX-SL5700 Ver. 1.3 Ver. 1.01
NX-SIH400 Ver. 1.0 Ver. 1.00
NX-SIH400 Ver. 1.1
NX-SID800 Ver. 1.0
NX-SOH200
NX-SOD400
EtherNet/IP Slave Terminal
This configuration is used to connect the Safety Control Unit to the EtherNet/IP Coupler Unit.
Safety Control Unit model and version NX bus master: EtherNet/IP Coupler Unit
Model Unit version
Communications Cou-
pler Unit
Sysmac Studio
NX-SL3300 Ver. 1.0 --- ---
Ver. 1.1 Ver. 1.0 Ver. 1.10
NX-SL3500 Ver. 1.0 --- ---
Ver. 1.1 --- ---
NX-SL5500 Ver. 1.3 --- ---
NX-SL5700 Ver. 1.2 --- ---
NX-SIH400 Ver. 1.0 --- ---
Ver. 1.1 Ver. 1.0 Ver. 1.10
NX-SID800 Ver. 1.0
NX-SOH200
NX-SOD400
