Category Device Settable external device icons

Generic Device Mechanical Contact for Single Channel

Mechanical Contact for Dual Channel

Equivalent

Mechanical Contact for Dual Channel

Complementary

Semiconductor Output for Single Chan-

nel

Semiconductor Output for Dual Channel

Equivalent

Semiconductor Output for Dual Channel

Complementary

Appendices

A - 88
