6-6-2
Automatic Programming Settings
To execute the automatic programming, you need to specify the following items on the Automatic Pro-
gramming Settings T
ab Page.
Reset signal
Input signal
Output signal
Expected value of the output signal corresponding to the input signal
You can open the Automatic Programming Settings Tab Page in either of the following procedures:
Select Automatic Programming from the Insert Menu.
In the Multiview Explorer, select ProgrammingPOUsPrograms. On the right-click menu, se-
lect Automatic Programming.
The Automatic Programming Settings Tab Page consists of the items shown in the following table.
6 Programming
6 - 71
NX-series Safety Control Unit User's Manual (Z930)
6-6 Automatic Programming
6
6-6-2 Automatic Programming Settings
