A-8-4

Contact Icons for Output Devices

Category Device Settable contact icons

Relays with Forcibly

Guided Contacts

Relays with Forcibly Guided Con-

tacts for Dual Channel

Load

Relays with Forcibly Guided

Contacts

Contactor

Relays with Forcibly Guided Con-

tacts for Single Channel

Load Relays with Forcibly Guided

Contacts

Contactor

Generic Device Single Channel with Test Pulse

Load Relays with Forcibly Guided

Contacts

Contactor

Single Channel without Test Pulse

Load Relays with Forcibly Guided

Contacts

Contactor

Dual Output with Test Pulse

Load

Relays with Forcibly Guided

Contacts

Contactor

Dual Output without Test Pulse

Load

Relays with Forcibly Guided

Contacts

Contactor

Appendices

A - 92

NX-series Safety Control Unit User's Manual (Z930)
