11.20 Parameters Changed by PM Motor Code Selection
506 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
No. Name Unit Motor Code (setting value of E5-01)
E5-07
PM q-Axis Inductance
(mH/Phase)
mH 5.39 3.90 3.23 2.46 2.08 1.88 1.51
E5-09
PM BackEMF Vpeak
(mV/(rad/ s))
mVs/rad 853.8 829.6 835.6 833.4 848.6 889.1 915.0
E5-24
PM BackEMF L-L
Vrms (mV/rpm)
mV/(r/
min)
0.0 0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Max Output Frequency Hz 57.5 57.5 57.5 57.5 57.5 57.5 57.5
E1-05 Max Output Voltage V 380.0 380.0 380.0 380.0 380.0 380.0 380.0
E1-06 Base Frequency Hz 57.5 57.5 57.5 57.5 57.5 57.5 57.5
E1-09 Min Output Frequency Hz 2.9 2.9 2.9 2.9 2.9 2.9 2.9
C5-17 Motor Inertia kgm
2
0.55 0.82 0.96 1.60 1.95 2.82 3.70
L3-24
*1
Acc@Rated Torque s 0.145 0.159 0.155 0.211 0.214 0.256 0.268
n5-02
Mot Inertia Acceleration
Time
s 0.145 0.159 0.155 0.211 0.214 0.256 0.268
n8-49 Heavy Load Id Current % -15.9 -15.7 -15.7 -14.7 -16.5 -14.1 -10.3
*1 Default settings vary depending on the setting of o2-04 [Drive KVA Selection].
