5.2 European Standards
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 179
Model Terminals
Recommended
Gauge
mm
2
Applicable Gauge
(IP20 Applicable
Gauge
*1
)
mm
2
Wire
Stripping
Length
*2
mm
Terminal Screw
Tightening Torque
N∙m (lb.∙in.)
Size Shape
4675
R/L1, S/L2, T/L3
R1/L11, S1/L21, T1/L31
120 × 4P
70 - 150 × 4P
(150 × 4P)
- M12 Hex self-locking nut
35
(310)
U/T1, V/T2, W/T3 95 × 4P
70 - 150 × 4P
(120 - 150 × 4P)
- M12 Hex self-locking nut
35
(310)
-, +1 95 × 4P
95 - 185 × 4P
(185 × 4P)
- M12 Hex self-locking nut
35
(310)
+3 70 × 4P
35 - 95 × 4P
(95 × 4P)
- M12 Hex self-locking nut
35
(310)
95 × 2P
60 - 150
(-)
- M12 Hex bolt (slotted)
32 - 40
(283 - 354)
*1 For IP20 protection, use wires that are in the range of applicable gauges.
*2 Remove insulation from the ends of wires to expose the length of wire shown.
*3 For wire gauges more than 30 mm
2
, tighten to a tightening torque of 4.1 N∙m to 4.5 N∙m (36 lb.∙in. to 40 lb.∙in.).
*4 Install an RCM/RCD with this wire gauge to maintain compliance with IEC/EN 61800-5-1:2007.
*5 Terminals - and +1 have two screws. The Recommended Gauge is the wire gauge for one terminal.
*6 A junction terminal is necessary to connect a braking resistor unit (LKEB-series) to terminals B1 and B2.
■ Connect a Fuse to the Input Side (Primary Side)
The drive circuit protection must comply with IEC/EN 61800-5-1:2007 for protection against a short circuit in the
internal circuitry. The manufacturer recommends connecting semiconductor protection fuses on the input side for
branch circuit protection.
WARNING! Electrical Shock Hazard. Do not immediately energize the drive or operate peripheral devices after the drive blows
a fuse or trips an RCM/RCD. Wait for the time specified on the warning label at a minimum and make sure that all indicators are
OFF. Then check the wiring and peripheral device ratings to find the cause of the problem. Contact the manufacturer before
energizing the drive or peripheral devices if the cause is not known. Failure to obey can cause death or serious injury and
damage to the drive.
*1 The manufacturer recommends a fuse with a large rated current for applications with repeated loads.
Table 5.2 Factory-Recommended Branch Circuit Protection (400 V Class)
Drive Model
Semiconductor Protection Fuse Rated Current
Manufacturer: EATON/Bussmann
4002 FWH-50B
4004 FWH-50B
4005 FWH-50B
4007 FWH-60B
4009 FWH-60B
4012 FWH-60B
4018 FWH-80B
4023 FWH-90B
4031 FWH-150B
4038 FWH-200B
4044 FWH-200B
4060 FWH-225A
4075 FWH-250A
4089 FWH-275A
Drive Model
Semiconductor Protection Fuse Rated Current
Manufacturer: EATON/Bussmann
4103 FWH-275A
4140 FWH-300A
4168
FWH-325A
FWH-400A
*1
4208 FWH-500A
4250 FWH-600A
4296 FWH-700A
4371 FWH-800A
4389 FWH-1000A
4453 FWH-1200A
4568 FWH-1200A
4675
FWH-1400A
FWH-1600A
*1
*1 A fuse with a large rated current for applications with repeated loads is recommended.
■ CE Standards Compliance for DC Power Supply Input
To comply with CE Standards, install a fuse for the DC power supply input.
Example for a DC power supply that has two drives connected in parallel.
To Next Page
Loading...
