3 - 113
3 Specifications
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
3-4 Cable and Connector Specifications
3
3-4-2 Motor Power Cable Specifications
 R88A-CA1KEBF
Applicable Servomotors
200 V:
1,500-r/min Servomotors of 7.5 kW, 11 kW, 15 kW
Cable types
Connection configuration and external dimensions [mm]
Wiring
*1. PE and shell are set in the connectors at Servomotor’s side.
Model Length [L]
Outer diameter
of sheath
Minimum bending
radius
Weight
R88A-CA1KE10BF 10 m 23.2 dia. 232 mm Approx. 12.8 kg
R88A-CA1KE20BF 20 m Approx. 25.2 kg
L
Servomotor
side
R88M-1
Servo Drive
side
R88D-1SN
Blue
Red
White
Green/Yellow
Servo Drive side
Cable
Servomotor side
Contact
Name
Phase U
Phase V
Phase W
Brake
Brake
Shield
Connector
Servomotor side connector
Power: 1623381
Brake: 1623604
1623328
1
2
Symbol
A
B
C
D
NC
FG
M40 Series (Phoenix Contact)
PE
*1
Shell
*1
Black
Black
16Sq × 4C UL758
AWG21 × 2C UL758
Contact
Name
Phase U
Phase V
Phase W
Brake
Brake
Shield
Connector
Servo Drive side connector
Power: 1623386
Brake: 1623611
1623358
1
2
Symbol
A
B
C
D
NC
FG
M40 Series (Phoenix Contact)
PE
*1
Shell
*1
