Omron R88D-1SN30F-ECT User Manual

A - 133
Appendices
AC Servomotors/Servo Drives 1S-series with Built-in EtherCAT® Communications User’s Manual (I586)
A-4 Sysmac Error Status Codes
A
A-4-2 Error Descriptions
Event name Main Circuit Power Supply Phase Loss Error Event code 28080000 hex
Description The phase loss of the main circuit power supply was detected.
Source
EtherCAT Master Function Mod-
ule
Source details
Slave
Detection
timing
Continuously
Error
attributes
Level
Minor fault
Recovery
Error reset
(after resetting
slave errors)
Log category
System log
Effects User program Continues. Operation Power drive circuit is OFF
Indicators
EtherCAT NET RUN EtherCAT NET ERR EtherCAT LINK/ACT
--- --- ---
System
-defined
variables
Variable Data type Name
None None None
Cause and
correction
Assumed cause Correction Prevention
Incorrect wiring, for example the
single-phase power supply is
input to a 3-phase input type
Servo Drive
Confirm the Servo Drive specifica-
tions, and perform the correct wir-
ing.
Confirm the Servo Drive specifica-
tions, and perform the correct wir-
ing.
In the case where the sin-
gle-phase power supply is input
to a single- and 3-phase input
type Servo Drive, the phase loss
detection is enabled.
Set Main Circuit Power Supply -
Phase Loss Detection Enable
(4320-02 hex) to 0 (disabled).
Disable the phase loss detection
when you input the single-phase
power supply to a single- and
3-phase input type Servo Drive.
The power supply voltage is low
or insufficient
Improve power supply conditions
by increasing the power supply
capacity or the like.
Improve power supply conditions
by increasing the power supply
capacity or the like.
Broken wiring of the main circuit
power supply input
Replace the main circuit power
supply input cable.
Confirm that the main circuit power
supply input cable is not broken
before use.
Servo Drive failure If this event occurs again after you
performed all corrections shown
above, replace the Servo Drive.
None
Attached
information
None
Precautions/
Remarks
AL status code: -, Error No.: 1301 hex
