S82J
S82J
6
Item
100 or 200 V
AC
(selectable)
100 or 200 V
AC
(selected
automatically)
100 to 240 V
AC input
Item
600 W300 W150 W100 W (5,
12, 15 V)
100 W
(24 V)
50 W25 W10 W
Other
Ambient temperature
Operating: See the derating curve in the Engineering Data section.
Storage: –25 to 65
°
C (with no condensation and icing)
Ambient humidity Operating: 25% to 85%
Storage: 25% to 90%
Dielectric strength
3.0 kV
AC, 50/60 Hz for 1 min (between all inputs and all outputs)
2.2 kV
AC, 50/60 Hz for 1 min (between all inputs and all inputs/GR terminal)
1.0 kV
AC, 50/60 Hz for 1 min (between all outputs and GR terminal)
Insulation resistance
100 M
Ω
min. (between all outputs and all inputs/GR terminals at 500 VDC)
V
ibration resistance
10 to 55 Hz, 0.375-mm double amplitude for 2 h each in X, Y
, and Z directions
Shock resistance
300 m/s
2
, 3 times each in
±
X,
±Y
, and
±
Z directions
T
erminal screw
tightening
0.74 N
S
m
1.08 N
S
m
Output indicator
Y
es (green)
Electromagnetic
interference (see note
2)
Conforms to FCC Class A
EMC
Emission Enclosure:
EN5501
1 class A
Emission AC Mains:
EN5501
1 class A
Immunity ESD:
EN61000-4-2:
4 kV contact discharge (level 2)
8 kV air discharge (level 3)
Immunity RF-interference: ENV50140:
10 Vm (80 MHz to 1 GHz) (level 3)
Immunity Conducted Disturbance:
ENV50141: 10 V (0.5 to 80 MHz) (level 3)
Immunity Burst:
EN61000-4-4:
2 kV power-line (level 3)
2 kV output line (level 4)
EMC standards
Conforms to EN50081-2 and EN50082-2
Conforms to
EN50081-2 and
EN50082-2 (see note 6)
With noise filter
,
confirms to EN50081-1
(see note 6 and 7)
Approved
standards
UL
UL508 (Listing), 1950, Class 2 (per UL1310)
UL508 (Listing), 1012, 1950 (see
note 8)
UL508/1012
CSA
CSA C22.2 No. 14, No. 950, Class 2
CSA C22.2 No. 14, No. 950
CSA EB1402C
VDE
EN50178 (VDE0160) and EN60950
T
erminal types (only terminal part): VDE0106/P100
W
eight (see note 9)
250 g
max.
350 g
max.
400 g max.
500 g
max.
1,000 g max.
2,000 g
max.
2,500 g
max.
Note: 1. DC
inputs not included in safety standard approvals.
2.
At 100% load for rated input voltage (100 V
AC or 200 V
AC).
3.
The output specification is defined at the power supply output terminals.
4.
For resetting, turn OFF the power supply
, leave for more than three minutes, and then turn ON the power supply
.
5. For
resetting, turn OFF the power supply
, leave for more than one minutes (90 seconds min. for the 300-W models and 3 minutes
min.
for the 600-W models), and then turn ON the power supply
.
6. T
o ensure the Emission Enclosure rating ferrite ring cores (recommended model: S82Y-JC-T) should be used on all cabling.
7. To
ensure the Emission AC Mains rating for EN50081-1 (only for 200-V
AC input), a noise filter (recommended models: S82Y
-JF3-N
for
300-W
, S82Y
-JF6-N for 600-W) should be used on the input lines.
8.
With UL508, 150-W connector type has “Recognized” approval.
9.
The weight indicated is the weight of the open-frame type. (Includes the covers for 300-W and 600-W models)
Reference Value
Item Value Definition
Reliability
(MTBF)
135,000 hours min.
MTBF stands for Mean T
ime Between Failures, which is calculated according to the
probability of accidental device failures, and indicates reliability of devices. Therefore,
it does not necessarily represent a life of the product.
Life expectancy
10 yrs. min.
The life expectancy indicates average operating hours under the ambient temperature
of 40
°
C and a load rate of 50%. Normally this is determined by the life expectancy of
the built-in aluminum electrolytic capacitor
.
