New S82K
New S82K
5
Ordering Information
3 to 240-W Mod els
Power ratings Output voltage Output current
Function Configuration
Models
Output Undervoltage
alarm
indicator/output
PFC
3W
5V 0.6 A
Single output Yes No
S82K-00305
12 V 0.25 A
S82K-00312
15 V 0.2 A S82K-00315
24 V 0.13 A S82K-00324
7.5 W
5V 1.5 A S82K-00705
12 V 0.6 A S82K-00712
15 V 0.5 A S82K-00715
24 V 0.3 A S82K-00724
+V12/--V12 0.3 A/0.2 A
Dual output
S82K-00727
+V15/--V15 0.2 A/0.2 A
S82K-00728
15 W
5V 2.5 A
Single output
S82K-01505
12 V 1.2 A
S82K-01512
24 V 0.6 A S82K-01524
30 W
5V 5.0 A S82K-03005
(see note 1)
12 V 2.5 A S82K-03012
24 V 1.3 A S82K-03024
50 W 24 V 2.1 A S82K-05024
90 W 24 V 3.75 A
Yes S82K-P09024
No S82K-09024
100 W 24 V 4.2 A
Yes S82K-P10024
(see note 2)
No S82K-10024
240 W 24 V 10 A
No S82K-24024T
(see note 3)
No
Yes S82K-P24024
No S82K-24024
Note:
1. The output capacity of the S82K-03005 is 25 W.
2. The output current during parallel operation is 3.78 A.
3. The output current during parallel operation is 9 A.
Model Number Legend
1. Power Factor Correction
None:No
P: Yes
2. Power Ratings
003: 3 W
007: 7.5 W
015: 15 W
030: 30 W
050: 50 W
090: 90 W
100: 100 W
240: 240 W
3. Output Voltage
05: +5 VDC
12: +12 VDC
15: +15 VDC
24: +24 VDC
27:
!
12 VDC
28:
!
15 VDC
4. Undervoltage alarm indicator/output
<For 3- to 100-W models>
None: Yes
<For 240-W models>
None:No
T: Yes
05: +5 VDC
12: +12 VDC
15: +15 VDC
24: +24 VDC
27:
!
12 VDC
28:
!
15 VDC
S82K -
1 2 3 4
Accessories (Order Separately)
Mounting T rack
50 cm (l)
×
7.3 mm (t) PFP-50N
1m(l)
×
7.3 mm (t) PFP-100N
1m(l)
×
16 mm (t) PFP-100N2
Noise Filter
for 3- to 50-W models S82Y-JF3-N
for 90-W and 100-W models S82Y-JF6-N
To Next Page
