New S82K
New S82K
10
90-/100-/240-W models with PFC (S82K-P
jjj
24 models)
Item
Single output
90 W 100 W 240 W
Other
Ambient temperature
Operating: See the derating curve in the Engineering Data section (No condensation or icing)
Storage: --25
"
Cto65
"
C (no condensation or icing)
Ambient humidity
Operating: 25% to 85%
Storage: 25% to 90%
Dielectric strength
3,000 VAC at 50/60 Hz for 1 min. (between all inputs and outputs)
2,000 VAC at 50/60 Hz for 1 min. (between all inputs and GR terminal)
1,000 VAC at 50/60 Hz for 1 min. (between all outputs and GR terminal)
Alarm current: 20 mA (90- and 100-W models) 25 mA (240-W models)
Insulation resistance
100 M
#
min. at 500 VDC (between all outputs and all inputs/GR terminal)
Vibration resistance
Malfunction:10 to 55 Hz, 0.375-mm single amplitude for
2 hrs each in X, Y, and Z directions
Malfunction:10 to 55 Hz, 0.15-mm
single amplitude for 2 hrs
each in X, Y, and Z
directions
Shock resistance
Malfunction:150 m/s
2
, 3 times each in
!
X,
!
Y, and
!
Z
directions
Malfunction:300 m/s
2
, 3 times each in
!
X,
!
Y, and
!
Z directions
Screw tightening
torque
0.74 N
S
m max. (see note 2)
Output indicator
Yes (Green)
Electromagnetic
interference
(see note 1)
Conforms to FCC class A
EMC (see note 3, 4)
90-, 100-W Models
(EMI): EN50081-1
Harmonic Current: EN61000-3-2 (200 VAC input only)
Emission Enclosure: EN55022 class B
Emission AC Mains: EN55022 class B
Emission Output Ports: EN55022 class A (with a recommended optional filter) (see note 3)
240-W Model
(EMI): EN50081-2
Harmonic Current: EN61000-3-2
Emission Enclosure: EN55011 class A (see note 4)
Emission AC Mains: EN55011 class A
Common to All Models
(EMS): EN50082-2
Immunity ESD: EN61000-4-2: 4-kV contact discharge (level 2)
8-kV air discharge (level 3)
Immunity Burst: EN61000-4-4: 2-kV power-line (level 3)
2-kV output line (level 4)
Immunity Surge: EN61000-4-5: between 2-kV lines (except for 240-W models)
between 4-kV line and FG (except for 240-W models)
Approved standards
Class 2 (UL1310)/Class 2 (CSA C22.2 No. 950) (see
note 5)
UL508 (Listing)/1950
CSA C22.2 No. 14/No. 950, EN50178 (VDE160),
EN60950
Conforms to VDE0106/P100
UL508 (Listing)/1012
CSA C22.2 No. 14/E.B. 1402C,
EN50178 (VDE160), EN60950,
Conforms to VDE0106/P100
Weight
1,000 g max. 2,200 g max.
Note:
1. Defined with a 100% load and the rated input voltage (100 or 200 VAC)
2. Do not press down on the terminal block with a force exceeding 75 N while tightening the terminals.
3. To ensure the Emission Enclosure ratings, a noise filter should be used on the output lines at the closest point. (90- and 100-W
models: S82Y-JF6-N)
4. To ensure the Emission Enclosure rating, a ferrite ring core should be used on all cables.
5. To meet Class-2 requirements with the 100-W model, either a fuse or circuit breaker that is UL listed or CSA certified, and rated at
4.2 A max. should be wired in series with the load to be connected to the power supply. Only then can the power supply output be
considered as meeting Class 2.
Reference Value
Item Value Definition
Reliability (MTBF)
135,000 hrs min. MTBF stands for Mean Time Between Failures, which is calculated according to the
probability of accidental device failures, and indicates reliability of devices.
Therefore, it does not necessarily represent a life of the product.
Life expectancy
8yrs.min. The life expectancy indicates average operating hours under the ambient
temperature of 40
"
C and a load rate of 50%. Normally this is determined by the life
expectancy of the built-in aluminum electrolytic capacitor.
