12 Switch Mode Power Supply S82K
■ Accessories
4.5
15 25 25 25 25
10 10
1,000 (500)
7.3±0.15
35±0.3
27±0.15
1
15 (5)
4.5
15 25 25 25 25 15
10 10
1,000
35±0.3
27 24
16
29.2
11.5
(See note.)
(See note.)
PFP-100N2
DIN Rail (Order Separately)
PFP-100N/PFP-50N
Note: The values shown in parentheses are for the
PFP-50N.
39±0.5
B±1
D±1
6.5
4
6.5
C±0.5
4
47±1
16 max.
A max.
Six, M4
16 max.
Nameplate
Two, 4.8 dia.
(Mounting
holes)
Noise Filter (Order Separately)
S82Y-JF3-N for 3- to 50-W Models
S82Y-JF6-N for 90- and 100-W Models
