Omron S8FS-G Series User Manual

S8FS-G
13
Connections
Block Diagrams
Voltage
detection
circuit
Photocoupler
Over voltage
detection
circuit
Control
circuit
Over current
detection
circuit
+V
-V
DC OUTPUT
Noise filter
Fuse
250 VAC
Inrush current
protection
15/30 W: 3.15 A
50 W: 4 A
HBC
AC(L)
INPUT
AC(N)
Rectifier Smoothing
circuit
Rectifier
smoothing circuit
S8FS-G015@@@ (15 W)
S8FS-G030@@@ (30 W)
S8FS-G050@@@ (50 W)
S8FS-G100@@@ (100 W)
S8FS-G150@@@ (150 W)
-V
-V
DC OUTPUT
+V
+V
+RC
-RC
REMOTE CONTROL
Only Remote control
AC(L)
INPUT
AC(N)
100 W: 8 A
150 W: 10 A
HBC
Voltage
detection
circuit
Photocoupler
Over voltage
detection
circuit
Control
circuit
Over current
detection
circuit
Noise filter
Inrush current
protection
Rectifier Smoothing
circuit
Rectifier
smoothing circuit
Fuse
250 VAC
