Omron S8FS-G Series User Manual

S8FS-G
2
Ordering Information
List of Models
Note: For details on normal stock models, contact your nearest OMRON representative.
With Cover/DIN Rail Mounting
Note: Ask your OMRON representative for pricing information on optional models.
*1. The output electric power is 40 W.
*2. The output electric power is 80 W.
*3. The output electric power is 105 W.
*4. Applicable to products produced from May 2018.
With Cover/DIN Rail Mounting (Extended hold time type)
Power ratings Input voltage Output voltage (VDC) Output current Built-in fan Model
15 W
100 to 240 VAC
(Permissible range
85 to 264 VAC,
80 to 370 VDC)
*4
5 V 3 A
None
S8FS-G01505CD
12 V 1.3 A S8FS-G01512CD
15 V 1 A S8FS-G01515CD
24 V 0.65 A S8FS-G01524CD
30 W
5 V 6 A S8FS-G03005CD
12 V 3 A S8FS-G03012CD
15 V 2.4 A S8FS-G03015CD
24 V 1.5 A S8FS-G03024CD
50 W
5 V 8 A *1 S8FS-G05005CD
12 V 4.3 A S8FS-G05012CD
15 V 3.5 A S8FS-G05015CD
24 V 2.2 A S8FS-G05024CD
100 W
5 V 16 A *2 S8FS-G10005CD
12 V 8.5 A S8FS-G10012CD
15 V 7 A S8FS-G10015CD
24 V 4.5 A S8FS-G10024CD
150 W
5 V 21 A *3 S8FS-G15005CD
12 V 13 A S8FS-G15012CD
15 V 10 A S8FS-G15015CD
24 V 6.5 A S8FS-G15024CD
48 V 3.3 A S8FS-G15048CD
300 W
100 to 240 VAC
(Permissible range
85 to 264 VAC,
120 to 370 VDC)
12 V 25 A
Yes
S8FS-G30012CD
15 V 20 A S8FS-G30015CD
24 V 14 A S8FS-G30024CD
48 V 7 A S8FS-G30048CD
600 W
100 to 240 VAC
(Permissible range
85 to 264 VAC,
120 to 350 VDC)
12 V 50 A S8FS-G60012CD
15 V 40 A S8FS-G60015CD
24 V 27 A S8FS-G60024CD
48 V 13 A S8FS-G60048CD
Power ratings Input voltage Output voltage (VDC) Output current Built-in fan Model
300 W
100 to 240 VAC
(Permissible range
85 to 264 VAC,
120 to 370 VDC)
24 V
14 A
Yes
S8FS-G30024CD-H
600 W
100 to 240 VAC
(Permissible range
85 to 264 VAC,
120 to 350 VDC)
27 A S8FS-G60024CD-H

Omron S8FS-G Series Specifications

General

Brand	Omron
Model	S8FS-G Series
Category	Power Supply
Language	English
