Omron S8FS-G Series User Manual

S8FS-G
4
Specifications
* Refer to Ratings, Characteristics, and Functions on page 11.
Power rating 15 W
Item Output voltage 5 V 12 V 15 V 24 V
Efficiency *
100 VAC input 80% typ. 84% typ. 84% typ. 85% typ.
200 VAC input 80% typ. 84% typ. 84% typ. 86% typ.
230 VAC input 80% typ. 84% typ. 84% typ. 86% typ.
Input
Voltage range * Single phase, 85 to 264 VAC, 80 to 370 VDC
Frequency * 50/60 Hz (47 to 450 Hz)
Current *
100 VAC input 0.32 A typ.
200 VAC input 0.2 A typ.
Power factor ---
Leakage current *
100 VAC input 0.5 mA max.
200 VAC input 1 mA max.
Inrush current *
(for a cold start at
25°C)
100 VAC input 14 A typ.
200 VAC input 28 A typ.
Output
Rated Output Current 3 A 1.3 A 1 A 0.65 A
Voltage adjustment range * −10% to 15% (with V.ADJ)
Ripple & Noise
voltage *
100 to 240 VAC input 40 mVp-p max. 40 mVp-p max. 40 mVp-p max. 60 mVp-p max.
Input variation influence * 0.5% max.
Load variation influence * 1.0% max.
Temperature
variation influence
100 to 240 VAC input 0.05%/°C max.
Startup time *
100 VAC input 1,000 ms max.
200 VAC input 1,000 ms max.
Hold time *
100 VAC input 15 ms typ. 14 ms typ. 15 ms typ. 15 ms typ.
200 VAC input 75 ms typ. 70 ms typ. 75 ms typ. 70 ms typ.
Additional
functions
Overload protection Yes, automatic reset
Overvoltage protection *
Yes, 120% or higher of rated output voltage, power shut off (shut off the input voltage and turn on
the input again)
Overheat protection No
Series operation Yes (For up to two Power Supplies, external diodes are required.)
Parallel operation No (However, backup operation is possible, external diodes are required.)
Remote sensing No
Remote control No
Output indicator Yes (LED: Green)
Insulation
Withstand voltage
3 kVAC for 1 min. (between all input terminals and output terminals) current cutoff 20 mA
2 kVAC for 1 min. (between all input terminals and PE terminals) current cutoff 20 mA
1 kVAC for 1 min. (between all output terminals and PE terminals) current cutoff 20 mA
Insulation resistance 100 MΩ min. (between all output terminals and all input terminals/PE terminals) at 500 VDC
Environment
Ambient operating temperature −20 to 70°C (Derating is required according to the temperature.) (with no condensation or icing)
Storage temperature −25 to 75°C (with no condensation or icing)
Ambient operating humidity 90% max. (Storage humidity: 90% max.)
Vibration resistance 10 to 55 Hz, 4.5 G max., 0.375-mm half amplitude for 2 h each in X, Y, and Z directions
Shock resistance 150 m/s
2
, 3 times each in ±X, ±Y, ±Z directions
Reliability
MTBF 135,000 hrs min.
Life expectancy * 10 years min.
Construction
Dimensions (W×H×D) Refer to Dimensions on page 19.
Weight 250 g
Cooling fan No
Degree of protection ---
Standards
Harmonic current emissions Conforms to EN 61000-3-2
EMI *
Conducted Emissions Conforms to EN 61204-3 Class B, EN 55011 Class B
Radiated Emissions Conforms to EN 61204-3 Class B, EN 55011 Class B
EMS Conforms to EN 61204-3 high severity levels
Safety Standards
UL 508 (Listing, excluding models with connector option)
UL 60950-1, UL 62368-1 (Recognition, OVCII [≤ 3,000 m], Pol2)
CSA C22.2 No.107.1 (excluding models with connector option)
CSA C22.2 No.60950-1, No.62368-1 (excluding models with connector option)
EN 50178 (OVCIII [≤ 2,000 m], OVCII [> 2,000 m and ≤ 3,000 m], Pol2)
EN/IEC 60950-1, EN/IEC 62368-1 (OVCII [≤ 3,000 m], Pol2)
Conforms to EN/IEC 61558-2-16
Conforms to PELV (EN/IEC 60204-1)
Marine Standards No
SEMI Conforms to F47-0706 (200 VAC input)
