Omron S8FS-G Series User Manual

S8FS-G
3
With Cover/Direct Mounting
Note: 1. Ask your OMRON representative for pricing information on optional models.
2. Front-mounting is not possible.
To mount a Power Supply from the front, purchase a DIN Rail-mounting Power Supply and a Front-mounting Bracket (sold separately).
Refer to page 27.
With Cover/Direct Mounting (Extended hold time type)
With Cover/Direct Mounting (Connector type)
*1. The output electric power is 40 W.
*2. The output electric power is 80 W.
*3. The output electric power is 105 W.
*4. Applicable to products produced from May 2018.
Power ratings Input voltage Output voltage (VDC) Output current Built-in fan Model
15 W
100 to 240 VAC
(Permissible range
85 to 264 VAC,
80 to 370 VDC)
*4
5 V 3 A
None
S8FS-G01505C
12 V 1.3 A S8FS-G01512C
15 V 1 A S8FS-G01515C
24 V 0.65 A S8FS-G01524C
30 W
5 V 6 A S8FS-G03005C
12 V 3 A S8FS-G03012C
15 V 2.4 A S8FS-G03015C
24 V 1.5 A S8FS-G03024C
50 W
5 V 8 A *1 S8FS-G05005C
12 V 4.3 A S8FS-G05012C
15 V 3.5 A S8FS-G05015C
24 V 2.2 A S8FS-G05024C
100 W
5 V 16 A *2 S8FS-G10005C
12 V 8.5 A S8FS-G10012C
15 V 7 A S8FS-G10015C
24 V 4.5 A S8FS-G10024C
150 W
5 V 21 A *3 S8FS-G15005C
12 V 13 A S8FS-G15012C
15 V 10 A S8FS-G15015C
24 V 6.5 A S8FS-G15024C
48 V 3.3 A S8FS-G15048C
300 W
100 to 240 VAC
(Permissible range
85 to 264 VAC,
120 to 370 VDC)
12 V 25 A
Yes
S8FS-G30012C
15 V 20 A S8FS-G30015C
24 V 14 A S8FS-G30024C
48 V 7 A S8FS-G30048C
600 W
100 to 240 VAC
(Permissible range
85 to 264 VAC,
120 to 350 VDC)
12 V 50 A S8FS-G60012C
15 V 40 A S8FS-G60015C
24 V 27 A S8FS-G60024C
48 V 13 A S8FS-G60048C
Power ratings Input voltage Output voltage (VDC) Output current Built-in fan Model
300 W
100 to 240 VAC
(Permissible range
85 to 264 VAC,
120 to 370 VDC)
24 V
14 A
Yes
S8FS-G30024C-H
600 W
100 to 240 VAC
(Permissible range
85 to 264 VAC,
120 to 350 VDC)
27 A S8FS-G60024C-H
Power ratings Input voltage Output voltage (VDC) Output current Built-in fan Model
15 W
100 to 240 VAC
(Permissible range
85 to 264 VAC,
80 to 370 VDC)
*4
24 V
0.65 A
None
S8FS-G01524CE
30 W 1.5 A S8FS-G03024CE
50 W 2.2 A S8FS-G05024CE
100 W 4.5 A S8FS-G10024CE
150 W 6.5 A S8FS-G15024CE
