Omron S8VM - Ordering Information

2 Switch Mode Power Supply S8VM
Ordering Information
Note: For details on normal stock models, contact your nearest OMRON representative.
Note: 1. No outputs are built into these models.
2. The output capacity of the S8VM-15005@@ is 135 W.
3. M8 bolts and nuts for the output terminals are not included with the S8VM-15224C.
4. The 300-, 600-, and 1,500-W models have fans.
5. To perform front mounting using the bottom mounting models, use the Mounting Brackets (S82Y-VM@@F, sold separately).
Configura-
tion
Power
ratings
Input voltage Output voltage Output current Bottom mounting DIN Rail mounting bracket
Standard model Undervoltage alarm model Standard model Undervoltage alarm model
Sinking Sourcing Sinking Sourcing
Open-frame
type
15 W 100 to 240 VAC 5 V 3 A S8VM-01505 --- --- S8VM-01505D --- ---
12 V 1.3 A S8VM-01512 --- --- S8VM-01512D --- ---
15 V 1 A S8VM-01515 --- --- S8VM-01515D --- ---
24 V 0.65 A S8VM-01524 --- --- S8VM-01524D --- ---
30 W 5 V 6 A S8VM-03005 --- --- S8VM-03005D --- ---
12 V 2.5 A S8VM-03012 --- --- S8VM-03012D --- ---
15 V 2 A S8VM-03015 --- --- S8VM-03015D --- ---
24 V 1.3 A S8VM-03024 --- --- S8VM-03024D --- ---
50 W 5 V 10 A S8VM-05005 --- --- S8VM-05005D --- ---
12 V 4.3 A S8VM-05012 --- --- S8VM-05012D --- ---
15 V 3.5 A S8VM-05015 --- --- S8VM-05015D --- ---
24 V 2.2 A S8VM-05024 --- --- S8VM-05024D --- ---
100 W 5 V 20 A S8VM-10005 --- --- S8VM-10005D --- ---
12 V 8.5 A S8VM-10012 --- --- S8VM-10012D --- ---
15 V 7 A S8VM-10015 --- --- S8VM-10015D --- ---
24 V 4.5 A S8VM-10024 --- --- S8VM-10024D --- ---
150 W 5 V 27 A S8VM-15005
(See note 2.)
--- --- S8VM-15005D
(See note 2.)
--- ---
12 V 12.5 A S8VM-15012 --- --- S8VM-15012D --- ---
15 V 10 A S8VM-15015 --- --- S8VM-15015D --- ---
24 V 6.5 A S8VM-15024 --- --- S8VM-15024D --- ---
Covered
type
15 W 100 to 240 VAC 5 V 3 A S8VM-01505C --- --- S8VM-01505CD --- ---
12 V 1.3 A S8VM-01512C --- --- S8VM-01512CD --- ---
15 V 1 A S8VM-01515C --- --- S8VM-01515CD --- ---
24 V 0.65 A S8VM-01524C S8VM-01524A (See note 1.) S8VM-01524CD S8VM-01524AD (See note 1.)
30 W 5 V 6 A S8VM-03005C --- --- S8VM-03005CD --- ---
12 V 2.5 A S8VM-03012C --- --- S8VM-03012CD --- ---
15 V 2 A S8VM-03015C --- --- S8VM-03015CD --- ---
24 V 1.3 A S8VM-03024C S8VM-03024A (See note 1.) S8VM-03024CD S8VM-03024AD (See note 1.)
50 W 5 V 10 A S8VM-05005C --- --- S8VM-05005CD --- ---
12 V 4.3 A S8VM-05012C --- --- S8VM-05012CD --- ---
15 V 3.5 A S8VM-05015C --- --- S8VM-05015CD --- ---
24 V 2.2 A S8VM-05024C S8VM-05024A S8VM-05024P S8VM-05024CD S8VM-05024AD S8VM-05024PD
100 W 5 V 20 A S8VM-10005C --- --- S8VM-10005CD --- ---
12 V 8.5 A S8VM-10012C --- --- S8VM-10012CD --- ---
15 V 7 A S8VM-10015C --- --- S8VM-10015CD --- ---
24 V 4.5 A S8VM-10024C S8VM-10024A S8VM-10024P S8VM-10024CD S8VM-10024AD S8VM-10024PD
150 W 5 V 27 A S8VM-15005C
(See note 2.)
--- --- S8VM-15005CD
(See note 2.)
--- ---
12 V 12.5 A S8VM-15012C --- --- S8VM-15012CD --- ---
15 V 10 A S8VM-15015C --- --- S8VM-15015CD --- ---
24 V 6.5 A S8VM-15024C S8VM-15024A S8VM-15024P S8VM-15024CD S8VM-15024AD S8VM-15024PD
300 W
(See note
4.)
5 V 60 A S8VM-30005C --- --- --- --- ---
12 V 27 A S8VM-30012C --- --- --- --- ---
15 V 22 A S8VM-30015C --- --- --- --- ---
24 V 14 A
Peak current:
16.5 A (200 VAC)
S8VM-30024C --- --- --- --- ---
600 W
(See note
4.)
5 V 120 A S8VM-60005C --- --- --- --- ---
12 V 53 A S8VM-60012C --- --- --- --- ---
15 V 43 A S8VM-60015C --- --- --- --- ---
24 V 27 A
Peak current:
31 A (200 VAC)
S8VM-60024C --- --- --- --- ---
1,500 W
(See note
4.)
24 V 65 A (100 VAC)
70 A (200 VAC)
Peak current:
105 A (200 VAC)
S8VM-15224C
(See note 3.)
--- --- --- --- ---
