Omron S8VM - Mounting Brackets

26 Switch Mode Power Supply S8VM
■ Mounting Brackets
Mounting Bracket A (Bottom Mounting for 15-, 30-, and 50-W Models)
Mounting Bracket B (Bottom Mounting for 100-, and 150-W Models)
Name Model
Mounting Bracket A (bottom mounting for 15-, 30-, and 50-W models) S82Y-VM10B
Mounting Bracket B (bottom mounting for 100- and 150-W models) S82Y-VM20B
Mounting Bracket C (front mounting for 15-, 30-, 50-, 100-, and 150-W models) S82Y-VM10F
Mounting Bracket D (bottom mounting for 300-W models) S82Y-VM30B
Mounting Bracket E (horizontal bottom mounting for 300-W models) S82Y-VM30S
Mounting Bracket F (front mounting for 300-W models) S82Y-VM30F
Mounting Bracket G (DIN Rail mounting for 300-W models) S82Y-VM30D
Mounting Bracket H (bottom mounting for 600-W models) S82Y-VM60B
Mounting Bracket I (horizontal bottom mounting for 600-W models) S82Y-VM60S
Mounting Bracket J (front mounting for 600-W models) S82Y-VM60F
Mounting Bracket K (DIN Rail mounting for 600-W models) S82Y-VM60D
150
35
20±0.5
7.5
4
R2
R2
4 dia.
140±0.5
5
t = 2.
3
5
Three, M3.5
c
a
c
b
a, c
b
a = Mounting holes for 15-W models
b = Mounting holes for 30-W models
c = Mounting holes for 50-W models
A
B
B
B
A
A
S82Y-VM10B
Using the Mounting Bracket
Screws Used
A: Accessories
(Use the enclosed screws in two
places for 15-W and 30-W models
and in three places for 50-W mod-
els.)
B: M3 or M3.5
(three places)
Mounting screw tightening torque
(recommended): 0.49 N·m
a
b
a
b
a
b
40
20±0.5
4
R2
4 dia.
5
192
15±0.2
182±0.5
Three, M3.5
t = 2.3
a = Mounting holes for 100-W models
b = Mounting holes for 150-W models
A
B
B
B
A
A
S82Y-VM20B
Using the Mounting Bracket
Screws Used
A: Accessories
(Use the enclosed screws in three
places.)
B: M3 or M3.5
(three places)
Mounting screw tightening torque (rec-
ommended): 0.49 N·m
