Omron S8VM - Mounting Holes

Switch Mode Power Supply S8VM 19
Dimensions
Note: All units are in millimeters unless otherwise indicated.
■ Bottom Mounting Models (15-W, 30-W, 50-W, 100-W, 150-W Models)
62±0.5
67±0.3
68±0.5
15.5±0.5
8.5±0.5
8.5±0.5
8.5±0.5
84.5
84.5
33.5
Two, M3 (depth: 8 max.)
Two, M3 (depth: 8 max.)
13.6 max.
8.5±0.5
8.5±0.5
Two, M3 (depth: 8 max.)
17.6 max.
8.5±0.5
27
81.5
80.5
62±0.5
68±0.5
15.5±0.5
67±0.3
Two, M3 (depth: 8 max.)
S8VM-015@@
S8VM-015@@C
S8VM-01524A
Note: The image is the S8VM-01524 Model.
Mounting Holes
Bottom View
Side
Mounting
Bottom
Mounting
62±0.5
68±0.5
Two, 4 dia.
67±0.3
Two, 4 dia.
Note: The image is the S8VM-01524A Model.
84.5
33.5
13.6 max.
99.5
8.5±0.5
68±0.5
77±0.5
82±0.3
8.5±0.5
15.5±0.5
8.5±0.5
Two, M3 (depth: 8 max.)
Two, M3 (depth: 8 max.)
8.5±0.5
8.5±0.5
27
95.5
82.5
68±0.5
8.5±0.5
15.5±0.5
77±0.5
82±0.3
17.6 max.
Two, M3 (depth: 8 max.)
Two, M3 (depth: 8 max.)
S8VM-030@@
S8VM-030@@C
S8VM-03024A
Note: The image is the S8VM-03024 Model.
Mounting Holes
Bottom View
Side
Mounting
Bottom
Mounting
77±0.5
68±0.5
Two, 4 dia.
82±0.3
Two, 4 dia.
Note: The image is the S8VM-03024A Model.
