Omron S8VM - Page 20

20 Switch Mode Power Supply S8VM
68±0.5
8.5±0.5
8.5±0.5
15±0.2
83±0.5
32.5±0.5
8±0.2
23.5±0.3
120.5
27
82.5
97±0.5
17.6 max.
Three, M3 (depth: 4 max.)
Two, M3 (depth: 8 max.)
8.5±0.5
97±0.5
15±0.2
8±0.2
23.5±0.3
124.5
84.5
83±0.5
32.5±0.5
68±0.5
8.5±0.5
33.5
13.6 max.
Three, M3 (depth: 4 max.)
Two, M3 (depth: 8 max.)
S8VM-050@@
S8VM-050@@C
S8VM-05024A
S8VM-05024P
Note: The image is the S8VM-05024 Model.
Mounting Holes
Bottom View
Side
Mounting
Bottom
Mounting
97±0.5
68±0.5
Two, 4 dia.
83±0.5
8±0.2
15±0.2
Three, 4 dia.
Note: The image is the S8VM-05024A Model.
82.5
17.6 max.
160.5
8.5±0.5
68±0.5
135±0.5
120±0.5
8.5±0.5
15±0.2
7.5±0.2
25±0.2
30±0.5
28.5
Three, M3
(depth: 4 max.)
Two, M3 (depth: 8 max.)
84.5
35
13.6 max.
164.5
8.5±0.5
68±0.5
135±0.5
120±0.5
8.5±0.5
15±0.2
7.5±0.2
25±0.2
30±0.5
Three, M3 (depth: 4 max.)
Two, M3 (depth: 8 max.)
S8VM-100@@
S8VM-100@@C
S8VM-10024A
S8VM-10024P
Note: The image is the S8VM-10024 Model.
Mounting Holes
Bottom View
Side
Mounting
Bottom
Mounting
68±0.5
135±0.5
Two, 4 dia.
120±0.5
7.5±0.2
15±0.2
Three, 4 dia.
Note: The image is the S8VM-10024A Model.
