Omron S8VM - Page 21

Switch Mode Power Supply S8VM 21
13.6 max.
44
84.5
164.5
120±0.5
25±0.5
135±0.5
8.5±0.5
8.5±0.5
68±0.5
7.5±0.2
15±0.2
26.5±0.2
Three, M3 (depth: 4 max.)
Two, M3 (depth: 8 max.)
17.6 max.
160.5
135±0.5
8.5±0.5
8.5±0.5
68±0.5
37.5
82.5
25±0.5
7.5±0.2
120±0.5
15±0.2
26.5±0.2
Three, M3 (depth: 4 max.)
Two, M3 (depth: 8 max.)
S8VM-150@@
S8VM-150@@C
S8VM-15024A
S8VM-15024P
Note: The image is the S8VM-15024 Model.
Note: The image is the S8VM-15024A Model.
Mounting Holes
Bottom View
Side
Mounting
Bottom
Mounting
68±0.5
135±0.5
Two, 4 dia.
120±0.5
7.5±0.2
15±0.2
Three, 4 dia.
